Application of GRP Pipes and Fittings

1. Pressure/Force Main Sewers.

2. Raw Water Transmission Line.

3. Potable Water Distribution Network.

4. Storm Water & Drainage Discharge System.

5. Industrial Pipeline.

6. Water and Waste Water Treatment Plant.

7. Open Trench Installation.

8. Micro-tunneling Jacking Pipe.

9. Bore Casing, Ventilation Shafts and Ducts.

10. Special Applications: Manhole Covers and Inspect Chambers.

Advantage of GRP Pipes and Fittings

1. Excellent chemical and corrosion resistance.

2. High stiffness to resist high load.

3. Smooth internal surface to achieve high hydraulic efficiency and abrasive resistance.

4. Resistant to UV light and frost.

5. Light weight.

6. Easy installation with Coupling Joint.

7. Customized fittings variety.

8. Angular accommodation allowed.

9. Long life with at least 50 years.

10. Safety and health.

Reference Standard of GRP Pipes and Fittings

AWWA C950

ASTM D3262/ASTM D3517/ASTM D3754

EN14364/EN1636/EN1796

ISO10467/ISO10639/ISO23856/ISO25780

Size Range of GRP Pipes and Fittings

Size: DN15—DN4000

Pressure Rating: Gravity—PN32

Ring Stiffness Class: SN2500—SN50000

Length:5.8M/6M/11.8M/12M or Customized

End Type: Plain End/Socket End/Flange End

Joint Type: Socket Spigot with Gasket/Coupling Connection/Butt and Wrap/Flange Connection


Socket Spigot with Gasket	Coupling Connection

Butt and Wrap	Flange Connection

Category of GRP Fittings

Bend (11.25°/22.5°/30°/45°/60°/90°)

Tee/Reducing Tee

Concentric Reducer/Eccentric Reducer

Integral Flange/Loose Flange

Manhole and Inspection Chamber

GRP Jacking Pipe

GRP Jacking Pipes are designed to meet the exacting demands of pipeline construction and rehabilitation using micro-tunnelling and pipe-relining methods.

Advantage of GRP Jacking Pipe

1. Corrosion resistance, maintenance free, long service life (more than 50 years)

2. Large conveying flow (GRP pipe N= 0.009-0.01; concrete pipe N= 0.013-0.014)

3. High strength and large longitudinal jacking force (GRP pipe ≥ 90Mpa)

4. The friction resistance between pipe wall and soil is small, and the construction jacking force is small

5. Light weight and convenient transportation and hoisting. For example, DN2000 concrete pipe jacking is 3499kg/m, while DN2000 GRP pipe jacking is 850kg/m.

6. Construction Earthwork can be reduced by 30% compared with concrete pipe

7. The construction speed is fast, which is three times that of concrete pipe

8. Strong differential settlement resistance

9. Pipeline that can be used for pressure transmission medium

10. It can transport highly corrosive media

Size Range of GRP Jacking Pipes

Diameters: DN300—DN4000

Ring Stiffness: SN20000—SN1000000

Coupling material: GRP, Carbon steel, Stainless Steel

Pipe lengths: 1M-5.8M

Ultimate Compressive Strength: 85N/mm²

Jacking Force Safety Factor: 3.5

Colebrook-White Coefficient: 0.01mm
